Bobcat Angle Broom

Widths: 52" - 64" - 68" - 84"

Efficiently sweep and clean with the hydraulically driven angle broom attachment
Heavy-duty broom bristles create a cleaner path and sweep more snow or debris in one pass
Reverse bristle rotation available on the 68-inch and 84-inch angle brooms for enhanced cleaning along curbs, corners and around obstacles
Reversible angle broom is available for all M-Series and R-Series compact track loaders and skid-steer loaders; as well as Toolcat™ utility work machines with the 7-pin attachment control kit

This system keeps the attachment centered on the machine and avoiding the risk of the attachment becoming offset. The unit stays centered in front of the machine to help with keeping the machine on the sidewalk, reducing damage to surfaces outside of the desired cleaning area.

Remove debris from curbs, gutters, corners, and obstacles by reversing the direction of the bristles (only available on 68-inch and 84-inch brooms).

The angle broom is driven by a hydraulic motor that rotates the broom at a continuous speed sweeping any dirt, snow, or debris away from the machine. The broom can also be angled in either direction to a maximum angle of 25 degrees, allowing the operator to sweep material to the side with ease. Reverse the rotation of the broom to easily sweep tough to access spots.

Bobcat Angle Broom
Model	48" Broom	52" Broom	64" Broom	68" Broom	84" Broom
Weight	260 lb.	355 lb.	385 lb.	860 lb.	944 lb.
Length	46.9 in.	48.3 in.	48.3 in.	61.8 in.	61.8 in.
Width	54.9 in.	54.5 in.	67.5 in.	79.6 in.	96.4 in.
Broom Angling	Manual	Hydraulic	Hydraulic	Hydraulic	Hydraulic
Broom Bristle Diameter	21.4 in.	26 in.	26 in.	32 in.	32 in.
Sweep Width - Fully Angled	41.5 in.	48 in.	60 in.	63 in.	77 in.
Sweep Width - Straight	48 in.	51.5 in.	63.5 in.	68 in.	84 in.
Flow Range	8-13 GPM	9-18 GPM	9-18 GPM	8-24 GPM	15-28 GPM

Good: Bobcat Poly Bristles (Flat & Convoluted)

These poly bristles have good rigidity for long life and deliver effective debris removal under normal sweeping conditions.

Better: Bobcat Standard Poly Bristles (Flat & Convoluted)

Bobcat standard-duty poly bristles are anything but average when it comes to effective debris removal for a variety of sweeping applications. Standard poly resin bristles provide a high level of flick action rigidity for great performance and long life. Under normal to severe sweeping conditions, these bristles provide effective debris removal. Available in flat and convoluted styles, standard poly bristles get the job done.

Best: Bobcat Heavy Duty Poly Bristles (Flat, Conical, & Convoluted)

Bobcat heavy-duty bristles are ideal for all sweeping surfaces and contain 15% more poly than standard bristles to handle more aggressive applications. Durable, long-lasting and high-quality virgin poly resin provides excellent flick action and more rigid work action to the ground under normal sweeping conditions. They are available in flat, conical and convoluted styles to cover a variety of applications.

Bristle Options for Bobcat Angle Broom

Bobcat Steel Wire Bristles (Convoluted)

Bobcat steel wire bristles sweep through the tough stuff. They are ideal when more action is needed to cut through difficult debris, like heavy millings or mud-packed roads. Corrosion- and rust-resistant flexible spring steel wire provides an aggressive and abrasive cutting action to break down debris without brittleness. Wire wafers are never used alone but in conjunction with poly bristle wafers. Available only in convoluted.

Bobcat Poly & Wire Combo Bristles (Convoluted)

These combo bristles include both poly and wire bristles on one wafer. They combine the flicking action of poly bristles with the aggressive cleaning ability of wire bristles. These bristles contain 0.028-inch (0.071 cm) thick spring steel for impactful sweeping action without brittleness. Available in convoluted only. With these bristles, you’ll be ready to take on just about anything.
